Properties | Specified as perIS:303-1989 | PLYWOODConforms |
---|---|---|
Adhesive used for Bonding | as per IS 848:1974 | |
Preservative treatment for plywood | as per IS 5539:1990 | |
Length of plywood(tolerance) | +6 mm. -0 mm. |
|
Width of plywood (tolerance) | as per IS 848:1974 | |
Thickness (tolerance) (1) Less than 6 mm. (2) 6 mm.And above |
+10% + 5% |
|
Squareness | 0.2% | |
Edge straightness | 0.2% | |
Glue Sheer Strength of plywood Dry State | -1350 N Min. Average -1000 N Min. Individual |
|
Mycological | -1000 N Min. Average - 800 N Min. Individual |
|
Wet State | -1000 N Min. Average - 800 N Min. Individual |
By using the selected species of Hard wood commercial grade plywood is free from the borrers and termites. It can be used for all interior purposes like furniture partitions,counters etc. Because of the management's commitment towards the development, implimentation and continual improvement of the quality of the products, Our brands are growing in the market share.
Marine Plywood is made out of highest quality hard wood . Its extremely rigid and can face anykind of wear and tear. It is dimensionally stable making it an ideal plywood for making high quality furniture, partitions etc.
Product | 100% Hardwood |
Density | 850 kgs/cbm |
Average glue shear strength in Dry state | 1150 n/mtr. |
Average glue shear strength in wet state | 900 n/mtr. |
Bending strength parallel to face grain | 700kg/sq.cm. |
Bending strength per particular to face grain | 400kg/sq.cm. |
Screw holding strength | Above 250 kgs. |
Nail holding strength | Above 70 kgs. |
Moisture Contain | 8% |
USED FOR FURNITURE, PARTITIONS AND INTERIORS USES. BANK COUNTERS,WARDROBES.
BLOCK BOARDS are available in both grades (exterior & interior COMMERCIAL AND MARINE). Battens are chemically treated and veneers are glue poisoned for powder proof. Battens are made out of 100% selected species of hardwood.The wood planks are thoroughly seasoned in our ultra modern seasoning kilter and then cut with great precision to obtain battens with unmatched uniform thickness.
These are ready -to-use doors with a sample-species hardwood core that is chemically treated and killen seasoned. Made out of high quality wood, Flush Doors are exceptionally durable and dimensionally stable - with unmatched finishing properties. The cross-bands are sourced and crafted from selected hardwood that is uniformly dried to the requisite moisture content.
Made from natural veneers of Indian and imported variety, our plywood offers gradient surface and the products are anti-wrap and dimensionally stable. The chemical treatment against termites,fungus, borer and other micro- organisms ensures that our plywood remains for ever. Our plywoods are remarkably strong and extraordinarily durable. It is not surprising that our brands are the first choice for Interior Designers, Builders and carpenter.Available in Natural Teak, Italian Teak, .. such as, Ash, Olive Ash, walnut etc.
We manufacture a multitude of chequered plywood that meets the specifications of the purposes it serves. Our team of workers to be great care in manufacturing our spectacular range of chequered plywood that is tested for quality of each level of its production. Our customers can avail our exotic range of chequered plywood that is available in different sizes.
Shuttering Grade Plywood is made out of select hard wood species and imported veneer of uniform quality. These veneers are dried and bonded with high quality phenol formaldehyde BWP grade resin, under controlled temperature & pressure. Plywood is finally treated with fixed type water soluble chemical preservation under vacuum pressure to ensure absolute protection against termite borer, fungus & other organism.
Concrete shuttering work, boxes for concrete columns, beams, slabs, wall, tanks, bridge, silos, mezzanine floors, truck and bus body building, kitchen cabinet, cooling towers and other exteriors.
Specific gravity | 0.65 to 0.75 |
Nail Holding strength | Above 100 kg. |
Screw Holding Strength | 250 kg. |
Bending strength | |
Along the grain | 450 kg. F/Cm2 |
Across the grain | 350 kg. F/Cm2 |
Tensile Strength | |
Along the grain | 450 kg. F/Cm2 |
Across the grain | 280 kg. F/cm2 |
Moisture Content | 8-10% z |
Boiling water | 72 Hr. at 100* C |
Module of Elasticity | 8000 N/mm2 approx |
